In the article, we talk about a clear, step-by-step guide on assembling, operating, and moving a Real Relax massage chair (Favor-03 for example). It covers unpacking the components, detailed installation instructions, safety precautions, and proper moving techniques. The guide ensures a smooth setup process and highlights important safety tips for users.

You will find it so easy to install.

Accessories from box

Step 1: Unpack the two packages, Take out the main body, armrest, footrest from the carton carefully.

Installation steps

1. First, lift the backrest.

2. When you hear a click, the backrest is installed.

3. Install the hook to main body.

4. Connect the air plug.

5. Install the bottom hook to the seat.

6. Fasten the armrest with screw

7. Next, install the seat, connect the two air plugs, and the wire firmly.

8. The chair pad is attached at the top with a zipper.

9. Next install the chair pad, The chair pad is attached at the top with a zipper. Connect the pad wire to the main unit.

10. Wheels should be pushed firmly into the back of the chair. Secure the wheel with screws.

11. Connect the remote to main body, install the remote bag to right armrest. Put the remote control into the bag, plug in the main power.

Turn on power supply

1. Plug the power cord into three core socket with well grounding.
2. Turn on the power switch on the bottom of massage chair.

CAUTION

(1) Before switching on the chair, please make sure there is no damage on the power wire and other exposed wires.

(2) Make sure the power switch is off before the chair is connected to electricity.

Move method

1. There are moving rollers at the bottom of the chair.

2. Raise the back to the highest point.

3. Switch off and plug out the chair.

4. Lift the front part of the chair as showed in the figure(one person raise the front part via holding moving holder, another person push the chair when holding the top of the chair), move the chair by the rollers.

CAUTION

Don't move it when there is people in it.

Don't use the armrest while moving the chair, only hold the moving holder in the back and front.
